EDGE SLAYER XL MOBILE SHREDDER
TWIN-SHAFT SHRED: MAX MOBILITY & UPTIME
A high-torque, slow-speed primary shredder built for flexibility on the move. It combines the proven performance of the Slayer XL with a fully mobile track-mounted design—delivering exceptional throughput, lower fuel use, and faster deployment between sites.
Designed for demanding applications, it processes bulky C&D debris, green waste, municipal waste, and industrial feedstock with ease. Intelligent load sensing and self-protection systems ensure continuous operation, while the robust twin-shaft chamber handles unpredictable material with minimal wear or downtime.
WEIGHT (TONNE)
26T (28.7UST)
TRANSPORT WIDTH
2.6M (8'6")
TRANSPORT LENGTH
10.65M (34'11")
TRANSPORT HEIGHT
WORKING WIDTH
WORKING LENGTH
WORKING HEIGHT
4.11M (13'6")
2.6M (8'6")
13.53M (44'4")
4.4M (14'9")
SLAYER XL MOBILE
COMPONENT OVERVIEW
.png)
.png)
• ENGINE POWER: CAT C13 420 hp / 310 kW (Tier 3–V options)
• SHREDDING CHAMBER: 6’5” × 6’6” / 1.96 m × 2.00 m twin shaft
• HOPPER CAPACITY: 4.6 yd³ / 3.5 m³ reinforced steel
• DISCHARGE CONVEYOR: 55” / 1,400 mm belt – 4.56 m (14’9”) height
• OPERATING WEIGHT: ≈ 57,300 lb / 26 t
• FUEL CONSUMPTION: 25–30 L/hr (7–8 USG/hr)
%20(4).png)
GO ELECTRIC WITH EDGE
.png)
.png)
IMPROVED PRODUCTIVITY
More power, torque, and faster shaft speed deliver high production capacity.
.png)
ADVANCED CONTROLS
New control system maximizes torque for longer, tougher applications.
.png)
ENHANCED ACCESSIBILITY
Larger chassis, fold-down sides, and cartridge shaft system make the unit highly accessible.
.png)
HIGH TORQUE & SPEED
Torque boosted from 90k Nm to 120k Nm; speed range expanded to 7–38 RPM.
.png)
EASY MAINTENANCE
Fuel, AdBlue, filters, and gauges are all accessible from one point.
.png)
INTELLEGENT PROTECTION
Smart system monitors shaft pressure and blocks non-shreddables to prevent damage.
SHREDDER APPLICATIONS
C&D WASTE
GREEN WASTE
MSW WASTE
TIRES
MATRESS
WHAT SETS THE Slayer XL MOBILE APART
Mobile High-torque primary shredder.
.png)
XL CHAMBER
A 1.96m×2m twin-shaft chamber handles large, irregular feedstock without bridging or clogging.
LOW FUEL USAGE
Efficient 420hp CAT engine uses only 25–30L/hr while maintaining consistent torque & throughput.
SELF-PROTECTION
Smart control logic detects non-shreds, reverses shafts, & enters limp mode to prevent damage.
HIGH-DISCHARGE CONVEYOR
1,400mm hydraulic folding conveyor provides a 4.56m discharge height for smooth material handling.
