FINLAY 883 TRIPLE SHAFT HEAVY DUTY SCREENER

883+Triple Shaft: 16'×5' oval-motion.

The Finlay® 883+ Triple Shaft is a high-capacity heavy-duty scalper for quarrying, mining, C&D, topsoil, recycling, sand & gravel, coal and ore. Its triple-shaft oval-motion screenbox runs two true 4.8×1.53m decks, delivering aggressive screening that resists blinding & plugging while maintaining high tonnage.

Key hardware includes quick media access (screenbox discharge end raises 500 mm), 1.2 m oversize, 800 mm mid (3.4 m discharge; 4.1 m with telescopic), and 900 mm fines (4.0 m discharge; 4.8 m extended). Standard T-Link telematics (7-year data) plus opt. hybrid/dual-power.

Protrack site charts (1024 x 768 px) (2400 x 1000 px) (2).png
WARRANTY, SERVICING
& FINANCING AVAILABLE
Untitled design (39).png

EXCLUSIVELY SOLD
IN BC BY PROTRACK

Finlay Logo_black_transparent_edited.png

  • NET ENGINE POWER

  • INLET OPENING

  • OPERATING WEIGHT

  • TRANSPORT DIMENSIONS

  • WORKING DIMENSIONS

Tier 3 - Cat 113.3hp - Tier 4F / Stage IV - Cat 110hp / Tier 3 - CAT 83kW | Tier 4F / Stage IV - Cat 82kW
Screen: 16’ x 5’ / 4.8 x 1.53m
68,340lbs / 31,000kg
Height 11' 2'' | Width 9' 10'' | Length 48' 8'' / Height 3.4m | Width 3m | Length 14.8m
Height 15' 5'' | Width 41' 4'' | Length 48' 8'' / Height 4.7m | Width 12.6m | Length 14.8m

CRUSHER APPLICATIONS

STONE &

HARD ROCK

Granite, basalt & ore

parts (13).png
materials (12).png

CONCRETE

& ASPHALT

C&D / recycle waste

materials (11).png
concrete and asphalt crushed (1).png

REBAR

& RUBBLE

Demolition debris

materials (9).png
rebar & bricks crushed.png

SAND &

AGGREGATES

Spec-grade sizing

materials (8).png
wood and bricks crushed.png

MIXED SITE MATERIAL

On-site cleanup

materials (10).png
wood and bricks crushed (2).png
Protrack site charts (1024 x 768 px) (2).png

LOWER YOUR OPERATING COSTS

Our Finlay equipment isn't just powerful—it's profitable. Here's how it reduces your bottom line:

WHAT SETS THE 883+ TRIPLE SHAFT APART

High G-force oval motion, fast access, & big stockpiles.

parts (3)_edited.png

3X SHAFT OVAL MOTION

Higher G-force & longer stroke for dry/sticky material and high output.

2-TRUE DECKS

16' × 5' decks with banana-profile bottom deck to maximise fines screening.

JACK UP DISCHARGE END

500mm for rapid media swaps; media, fit both standard & 3X-shaft boxes.

output-onlinepngtools (1)_edited.png

BIG BELTS & TILES

1.2m oversize; 800mm mid (to 4.1m); 900mm fines (to 4.8 m) + T-Link telematics standard.

Untitled design (43).png
review background (1).png

QUARRY FOREMAN, BC

Brent T.

“It chews through our hardest rock—quietly and efficiently. And setup is the fastest I’ve seen.”

A CLOSER COMPARISON

J-1480 left (8).png
Finlay J-1170 Jaw Crusher
Terex Finlay J 1170 (direct drive) jaw crusher & TF-75H high level feeder
Terex Finlay J 1170 jaw crusher, C 1540 cone crusher and 684 inclined screen
Terex Finlay J-1170 Jaw Crusher
Terex Finlay J 1170 Jaw Crusher 2 (Quarry)

WHY PROTRACK?

01

EXCLUSIVE CANADIAN DEALER

Your trusted source for Terex Finlay, Edge Innovative & used equipment.

03

LOCAL EXPERTISE

Bringing years of equipment knowledge & responsive service.

02

FULL ACCESS FINLAY LINEUP

Full line access to powerful Finlay Crushers, Screeners & more.

04

FULL SERVICE SUPPORT

Include training, delivery, financing, serivcing, parts & more.

parts (1080 x 1920 px) (1) (2)-min.png
protrack logo black (1000 x 1000 px).png
Finlay Logo_white_transparent.png

LET'S FIND THE BEST PLAN FOR YOUR SITE
